Big scale presence meets serious off‑road capability—designed for durability, realism, and thrilling trail performance out of the box.
Scale Design & Robust Bodywork
- Features a 1.5 mm-thick polycarbonate shell crafted from 30+ injection-molded parts including functional wipers, door handles, mirrors, steering wheel—delivering striking realism and rugged durability.
- Spring-loaded swivel clasp makes body removal and maintenance fast and secure.
Powertrain & Electronics
- Driven by a 4282‑size sensored brushless motor (~2200–2600 KV with magnetic encoding) and a 140 A FOC vector ESC supporting up to 4S LiPo. Enjoy smoother acceleration, responsive braking, and up to 20% greater energy efficiency compared to square-wave systems.
- Comes with a professional-grade 2.4 GHz 10-channel transmitter and receiver with up to 350 m control range.
Drivetrain & Terrain Control
- Full set of CNC chromium steel gears throughout the gearbox; high-strength pinion and spur gear at 1.0 cm expect reliable durability.
- Selectable drive modes: switch on-the-fly between full-time 4WD, front-wheel drive, or rear-wheel drive to optimize traction or descent control.
- Locking front and rear differentials give the flexibility needed for tight turns or technical terrain; unlock to enhance steering radius and cornering smoothness.
Stability & Steering
- Forward-located gearbox lowers center of gravity and helps reduce torque twist—improving climbing stability.
- Equipped with a 3‑link Panhard steering linkage system that reduces side-to-side body sway, especially through rough terrain or at speed.
Durability & Protection
- Twin friction-plate slipper clutch shields drivetrain components under heavy loads or sudden gear catches.
What’s Included / What You’ll Need
- Fully assembled crawler with brushless motor, ESC, and radio system.
- Battery and charger not included — requires your own XT60 connector LiPo (up to 4S supported).
Feature Snapshot
| Feature Description |
| Scale / Design | 1/7 scale with high-detail polycarbonate shell |
| Motor / ESC | 4282 sensored brushless (~2200–2600 KV) + 140 A FOC vector ESC (2–4S LiPo) |
| Transmission | CNC steel gears; 4WD / FWD / RWD selectable |
| Differentials | Lockable front and rear diffs |
| Stability Features | Forward gearbox, 3‑link Panhard steering layout |
| Protection | Twin friction slipper clutch |
| Electronics Included | 2.4 GHz 10-channel radio, servos |
| Standalone Power | Battery and charger sold separately (XT60) |
Why Choose the TK07 Brushless?
The TK07 represents a leap forward for full-scale trail crawling: it pairs premium all-metal gearing and intelligent drivetrain options with a high-efficiency brushless system. Whether you're navigating rock gardens, assaulting technical trails, or showcasing scale realism in events, the TK07 brings pro-level performance, scale fidelity, and rugged durability right out of the box.
Ready to climb? The TK07 awaits.
